Product Description
The FRP Cable Pipe Mold forms cable protection pipes via winding, pultrusion, or compression molding. It produces smooth, burr-free inner walls, uniform diameter and wall thickness, and tight tolerances for easy field alignment. The mold resists corrosion, wear, and deformation, handles resin curing, and lasts long in outdoor or underground use. Assembly and demolding are easy, with minimal resin sticking. It is reusable, simple to maintain, and lowers consumable costs.
Product Parameters
|
Parameter |
Specification |
|
Cable pipe diameter |
50 – 600 mm |
|
Cable pipe wall thickness |
3 – 20 mm |
|
Mold length |
2 – 12 m |
|
Mold accuracy |
±0.3 mm |
|
Working temperature |
-10 – 180°C |
|
Material hardness |
HRC 45 – 55 |
|
Mold weight |
Approx. 300 – 8000 kg |
|
Working pressure |
0.1 – 0.8 MPa |
Product Advantages
Prevents cable insulation damage that unpolished molds could cause during pipe production.
01
Maintains dimensional stability through more heating cycles than untreated steel molds.
02
Reduces scrap rate compared to molds without anti-stick coating.
03
Eliminates need for disposable release liners in high-volume runs.
04
Main Applications
This FRP Cable Pipe Mold is used for producing cable protection pipes including FRP cable pipes for power, municipal, telecom, and rail transit sectors. It serves underground cable laying and overhead cable protection, providing cable protection, insulation, and corrosion resistance. This mold is also referred to as a FRP cable duct mould,Fiberglass cable duct mould, or fiberglass cable conduit mould.
Frequently Asked Questions (FAQ)
Q: Can the same mold produce pipes with different wall thicknesses?
A: No. Wall thickness is fixed by the mold cavity. For different thicknesses, you need a different mold or adjustable winding parameters. Tell us your target thickness when ordering.
Q: How do you ensure the inner wall is smooth enough not to scratch cables?
A: The mold inner surface goes through multi-step polishing followed by chrome plating or anti-corrosion coating. Surface roughness is controlled below Ra 0.4 µm.
