The FRP Squatting Pan is a molded sanitary fitting made from chopped glass fiber and unsaturated polyester resin. A smooth finish makes the surface easier to wash, and the opening connects to the waste pipe beneath the floor. The composite body is relatively light to move during bathroom assembly. In a renovation, the existing pipe can limit where the fitting will sit. The shell dimensions and outlet position therefore need to work with that pipe, including the space available for the connection below.
Product Parameters
|
Item |
Value |
|
Thickness |
8–12 mm |
|
Load capacity |
≥ 150 kg |
|
Water absorption |
≤ 0.3% |
|
Surface roughness |
Ra ≤ 0.8 μm |
|
Service temperature |
−10 to 60 °C |
|
Slip-resistance range |
R10–R12 |
|
Drain opening diameter |
50–75 mm |
Dimensions and Finish Options
For a replacement FRP Squatting Pan, the bathroom drawing is most useful when it includes the waste pipe location. Weihan can review the dimensions and drain position before production. White and gray are standard finishes; other colors and custom molding can be discussed, with minimum quantities depending on the requested change.
After delivery, installation and maintenance guidance is available. If a quality issue needs attention, photographs showing the affected area and the order details help the team identify the fitting and understand the problem.
Allowing for the Finished Floor
An FRP Squatting Pan can fit the opening yet leave too little room underneath for the waste joint. Tiles and other floor finishes change the final level, so that space needs measuring at the finished height. Stable, level support keeps the fitting seated correctly. Connecting the waste pipe and testing drainage before sealing the surrounding floor leaves the joint accessible if an adjustment is needed.
FAQ
Q: What information is needed for a custom size?
A: Provide the finished installation dimensions, floor opening and waste pipe position.
Q: What should be inspected on delivery?
A: Check the FRP Squatting Pan surface for transport damage and compare its dimensions and outlet position with the order drawing. Raise discrepancies before the fitting is fixed in place.
Q: What is suitable for routine cleaning?
A: A soft cloth and compatible bathroom cleaner are suitable. Avoid abrasive tools that can mark the surface, and remove residue around the outlet before it accumulates.
